Supports digital video and audio signals without quality loss.
Maintains high-definition video resolution (up to 4K, 5K, or even 8K depending on version).
Compatible with DisplayPort versions 1.1, 1.2, 1.3, 1.4, or 2.0 (depending on the device).
Works with monitors, graphics cards, laptops, docking stations, and other DisplayPort-enabled devices.
Typically features male-to-female or female-to-female DisplayPort connectors.
Gold-plated contacts for improved corrosion resistance and signal integrity.
Allows extension of DisplayPort cables by joining two cables end-to-end.
Can be used to convert or join cables when longer cable lengths are required.
No driver or external power needed.
Simple to use: just plug into devices or cables.
Supports high bandwidth for smooth transmission of high-resolution video and multi-channel audio.
Suitable for HDR, 3D, and multi-stream transport (MST).
Sturdy build with durable materials (usually plastic housing with metal connectors).
Often comes with strain relief for cable protection.
অস্থির শীল বাজার ব্যবস্থার কারণে,
অর্ডার করার পূর্বে প্রোডাক্টের স্টক, ডেলিভারী সম্পর্কে বা দামের যেকোনো তথ্যের জন্য কল করুন: 01729525052 অথবা আমাদের মেসেজ করুন। আপনার সেবা করার জন্য আমরা প্রস্তুত।
DisplayPort to DisplayPort Joiner / Converter Specifications
| Specification | Details |
|---|---|
| Connector Type | Male DisplayPort to Female DisplayPort (Joiner) / Male-to-Male or Female-to-Female depending on type |
| Supported Versions | DP 1.1 / 1.2 / 1.3 / 1.4 (depends on device) |
| Maximum Resolution | Up to 4K@60Hz for DP 1.2, 8K@60Hz for DP 1.4 (depending on cable quality) |
| Bandwidth | Up to 17.28 Gbps (DP 1.2), 32.4 Gbps (DP 1.4) |
| Signal Type | Digital video/audio transmission |
| Audio Support | Multi-channel audio support |
| HDR Support | HDR10 / Dolby Vision (if DP 1.4 compatible) |
| Connector Locking | Yes, latch mechanism (for secure connection) |
| Cable Length Support | Typically up to 3m without active repeater; longer with active conversion |
| Power | Bus-powered from DisplayPort source |
| Additional Features | Some joiners are simple couplers; others include signal amplification or conversion between DP and mini-DP |
| Compliance | VESA standards compliance |
For more information
Call..01729525052
