ACARD Technology AEC-67162 (67162) Ultra160 SCSI LVD Controller Card — Key Features:
Dual-channel Ultra160 SCSI controller
Up to 160 MB/s data transfer per channel
LVD/SE SCSI support
64-bit/66 MHz PCI bus-master support; compatible with 32-bit/33 MHz PCI
Supports up to 15 SCSI devices per channel — up to 30 total
PCI bus mastering reduces CPU I/O load
Auto-termination control
CRC data protection for improved reliability
Domain Validation for optimized SCSI transfer speeds
Upgradeable onboard Flash BIOS
Supports up to 12 m LVD cable length
Uses an 80 MIPS RISC SCSI engine
Type: PCI Ultra160 SCSI controller/adapter
SCSI: Ultra160 LVD/SE
Channels: 2
Maximum transfer rate: 160 MB/s per channel
PCI interface: 64-bit/66 MHz PCI bus master; compatible with 32-bit/33 MHz PCI
Connectors: 2 × 68-pin SCSI connectors
Devices: Up to 15 SCSI devices per channel
LVD cable length: Up to 12 m
Termination: Automatic terminator control
BIOS: Upgradeable onboard Flash BIOS
Features: CRC data protection, domain validation, double-edge clocking
Power: 3.3 V and 5 V; maximum current about 0.5 A
RAID: No — standard SCSI host adapter
Model: ACARD AEC-67162
The manual identifies it specifically as a PCI-to-Ultra160 SCSI adapter, while compatibility documentation lists it at 160 MB/s and as a non-RAID controller.
